Laser Rangefinder Module

905nm single pulse 1HZ laser range finder module TTL RS232 600m/1000m/1500m.

As a rangefinder manufacturer, we support OEM/ODM/R&D service.




TAG:   laser rangefinder module laser rangefinder oem laser rangefinder odm
Tel: 8615639095718
Email: info@bosean.com
We’re here to help:Easy ways to get the answers you need
Send E-mail Get Price
Introduction
Bosean Laser Rangefinder Modules offer outstanding technical characteristics combined with an excellent price performance-ratio for the integration of length and/or position measurement systems, especially in the fields of industrial and security applications.
At an operational wavelength of 905nm the measurement range is 4 to 1500m with an measurement accuracy of +/-0.5m. The special processing electronics enable the Laser Rangefinder a maximum range capability within eye-safety class 1.
The production flow invoved by sequence are producing semiconductor circuit board, uploading software onto the board, cleaning eyepiece, assembling the prism for the eyepiece, checking the good condition of the internal LCD, ratifying the emission and reception lens, testing the correctness of ranging to finally assembling to a whole piece.Every process is closely checked to make sure our product defect free.

TAG:   laser rangefinder module laser rangefinder oem laser rangefinder odm
Specifications

Measurement Range

5-600m/1000m/1500m

Measurement Accuracy

±（0.5m±D*0.2%）

Measurement Time

0.1- 0.3s

Operating Temperature Range

0°C ~ 40°C

Storage Temperature Range

-20°C ~ 50°C

Unit Selection

M/YD

Laser Light Type

905nm

Eye Relief

3.8mm

Objective Caliber

24mm

Eyepiece Caliber

16mm

Magnification

7X

Range of Anger Measurement

＜±90º

Display Mode

LCD Screen

Field of View Angle

7º

Diopter Adjustable Range

±3º
